Myoplus 2 Channel Neuromuscular Biofeedback with 4 Channel Electrostimulation

* EMG stands for ElectroMyoGraphy. Biofeedback is a type of EMG conducted with surface adhesive electrodes

Features

Portable desktop device, two dual operation channels for EMG and muscle electrostimulation or four channels only electrostimulation, supplied with desktop stand, NiMH rechargeable battery and charger

Modes: EMG + electrostimulation (switching between phases of EMG and electrostimulation), EMG with triggered electrostimulation, muscle electrostimulation, EMG

Advanced stimulation treatments: sequential, alternating, modulated

Manual and automatic threshold control for EMG with triggered electrostimulation for each channel

Optical display of EMG or electrostimulation current as numerical value and graph bar and also acoustical indication for each channel

Designed for use in a wide range of applications in physiotherapy, sports, rehabilitation, continence and stroke therapy

Custom programs enabling up to 5 phases to be set up in one program with possibility for full parameter setting

Optional PC software Neurotrac with patients database, real time display of waveforms, data archive, comparison charts, automatic creation of reports, data statistical analysis, prints (with PC printer)

Used as a learning tool with emphasis on improving treatment protocols using EMG and neuromuscular electrostimulation

Portable, light and user friendly

Ready to use therapy programs with preconfigured therapy parameters organized in applications categories

Suggested therapy protocols (download from Attached Files)

Includes carrying case, desktop stand, cables, rechargeable Ni-MH battery, battery charger, adhesive electrodes, user manual

Programs
Urology
Sports
Rehabilitation
Custom program

Specifications EMG
Two channels
EMG range: 0.2 to 2000uV RMS (continuous)
Sensitivity: 0.1uV RMS
Accuracy: 4%
Selectable bandpass filter
Notch filter 50Hz for mains
CMRR: 130dB
Battery: 6V Ni-MH rechargeable
Charger: 12V DC
Work/Rest periods: 2-99 seconds
Number of trials: 1-99

Specifications Electrostimulation
Four channels
Amplitude: 0-90mA (500 Ohm load)
Constant current, maximum voltage 70Volts
Waveform: symmetrical, rectangular, bi-phasic with net zero DC
Pulse width: 50-450usec
Pulse rate: 2-100Hz
Work/Rest periods: 2-99 sec
Time: 1-99 minutes
Ramp up time: 0.1-9.9 sec
Preset and user programmable treatment programs
Automatic switch off when open electrode detected

Specifications Unit
Low battery indication, automatic switch off
Dimensions 150x96x36mm
Weight: 0.16kg unit, 0.2kg battery
